Name: ASTM A249 TP316L Bright Annealed Stainless Steel Welded Tubes , Used For Air Coolers
Brand: Yuhong Group Co.,Ltd
SKU: TP304, TP304L, TP316, TP316L, TP321, TP321H, TP310S, TP347H
Price: 100000 USD
Availability: InStock

Yuhong Holding Group Co., LTD

Dutch

ASTM A249 TP316L Bright Annealed Stainless Steel Welded Tubes , Used For Air Coolers

Productdetails:

Plaats van herkomst:	China
Merknaam:	YUHONG
Certificering:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Modelnummer:	TP304, TP304L, TP316, TP316L, TP321, TP321H, TP310S, TP347H

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	100 KG
Prijs:	Onderhandelbaar
Verpakking Details:	multiplex kast
Levertijd:	20-60 dagen
Betalingscondities:	T/T, L/C op zicht
Levering vermogen:	1000 ton per maand

Contact

Standaard:

ASTM A249/ASME SA249

Grondstofkwaliteiten:

TP304, TP304L, TP316, TP316L, TP321, TP321H, TP310S, TP347H, TP904L, ...

Buitendiameter:

6,35-152,4 mm

Wanddikte:

00,5-3,4 mm

Lengte:

6 meter of op maat

Eindigt:

Afgeschuind uiteinde, gewoon uiteinde, draaduiteinde

Oppervlakteafwerking:

Helder gegloeid, gebeitst en gegloeid, mechanisch gepolijst

Toepassingen:

Warmtewisselaar, ketel, verwarmingstoestellen, luchtkoelers, aardolie-industrie, voedselverwerkende

Markeren:

Parameter	Common Range
Outer Diameter (OD)	6.35mm to 152.4mm (1/4" to 6")
Wall Thickness (WT)	0.5mm to 3.4mm or As Requested
Length per Piece	Single Random Length (SRL): 4.0m – 7.0m Double Random Length (DRL): 7.0m – 13.0m

Element	Composition (Weight, %)
Carbon (C)	≤ 0.035
Manganese (Mn)	≤ 2.00
Phosphorus (P)	≤ 0.045
Sulfur (S)	≤ 0.030
Silicon (Si)	≤ 1.00
Chromium (Cr)	16.0 – 18.0
Nickel (Ni)	10.0 – 14.0
Molybdenum (Mo)	2.0 – 3.0
Nitrogen (N)	≤ 0.10 (max)

Finish Type	Description	Key Characteristic
Bright Annealed (BA)	Mirror-like, highly reflective surface produced by heat treatment in a reducing atmosphere. Oxide-free.	Highest corrosion resistance due to an intact, chromium-rich passive layer. No pickling required.
Pickled (AP)	Chemically cleaned to remove oxides; matte, dull grey finish.	Cost-effective, but rougher. Requires passivation post-pickling.
Mechanically Polished (MP)	Ground and polished post-annealing to achieve a specific shine.	Brighter than AP, but removes the as-annealed pristine surface layer.
