ASTM B423 UNS N08825 / DIN 2.4858 Seamless Pipe Inconel825 Nickel Alloy Pipe

Productdetails:

Plaats van herkomst:	China
Merknaam:	YUHONG
Certificering:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Modelnummer:	ASTM B423 Incoloy 825 nikkellegering naadloze buis

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	500 kg
Verpakking Details:	Ply-houten kist/ijzeren kist/bundel met plastic dop
Levertijd:	7 dagen
Betalingscondities:	L/C, T/T

Contact

Alle producten

Naadloze buizen van roestvrij staal (331)

Roestvrij staal Naadloze Buis (321)

Duplexroestvrij staalpijp (134)

Duplexroestvrij staalbuis (36)

Naaldbuis (152)

Vinnenbuis (699)

warmtewisselaar (25)

warmtewisselaarbuis (457)

Warmtewisselaarbuisbundel (46)

Warmtewisselaar Tubesheet (124)

warmtewisselaarschot (39)

Luchtkoeler (10)

Drukvat (4)

roestvrij staal gelaste pijp (61)

Roestvrij staal Gelaste Buis (132)

De Pijp van de nikkellegering (272)

De Buis van de nikkellegering (96)

De Buis van de koperlegering (247)

De Buis van het legeringsstaal (208)

Titaniumbuis (20)

heldere ontharde buis (172)

Boilerbuis (151)

staalmontage (856)

Staalflens (655)

Andere (404)

Bekledingsonderdelen (8)

Gedetailleerde productomschrijving

Productnaam:	Nikkellegering pijp	Standaard:	ASTM B423 / ASME SB423
Materiaal:	Incoloy 825 / UNS N08825 / DIN 2.4858	OD:	1/2" TOT 24" of groter
WT:	SCH 5S aan SCH XXS	Lengte:	Enkele willekeurige, dubbele willekeurige en snijlengte
Vorm:	Rechte buis, U-bocht buis	NDT:	WERVELSTROOMtest, HYDROSTATISCHE TEST
Type:	Naadloos	Sollicitatie:	Ketel, Warmtewisselaar, Chemische procesapparatuur, etc.
Markeren:	ASTM B423 Inconel825 seamless pipe , Nickel alloy pipe DIN 2.4858 , UNS N08825 corrosion resistant pipe

ASTM B423 UNS N08825 / Incoloy 825 Nickel Alloy Seamless Pipe

ASTM B423 UNS N08825 is the standard specification for seamless nickel-iron-chromium alloy pipe made from UNS N08825 (commonly known as Incoloy 825). It defines the chemical composition, mechanical properties, dimensions, and manufacturing requirements for a seamless tube product designed to resist corrosion in both reducing and oxidizing environments, especially containing sulfuric acid, phosphoric acid, and chlorides.

Manufacturing & Heat Treatment

Process: The seamless pipe is produced by hot finishing (extrusion) or cold finishing (drawing).

Condition: Typically supplied in the Solution Annealed & Pickled condition.

Heat Treatment: Heat to 1800°F – 1900°F (980°C – 1040°C), hold for sufficient time, then water quench or rapid air cool.

Chemical Composition of ASTM B423 Incoloy 825 Nickel Alloy Seamless Pipe

Element	%	Element	%
Nickel	38.0 – 46.0	Carbon	0.05 max
Chromium	19.5 – 23.5	Manganese	1.0 max
Molybdenum	2.5 – 3.5	Sulfur	0.03 max
Copper	1.5 – 3.0	Silicon	0.5 max
Titanium	0.6 – 1.2	Aluminium	0.2 max
Iron	22.0 min (~33%)

ASTM specifications for Incoloy Alloy 825.

Specification	Title
B163	Seamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes
B423	Nickel-Iron-Chromium-Molybdenum-Copper Alloy (UNS N08825 and N08221)* Seamless Pipe and Tube
B424	Ni-Fe-Cr-Mo-Cu Alloy (UNS N08825 and UNS N08221)* Plate, Sheet, and Strip
B425	Ni-Fe-Cr-Mo-Cu Alloy (UNS N08825)
B704	Welded UNS N06625 and UNS N08825 Alloy Tubes
B705	Nickel-Alloy (UNS N06625 and N08825) Welded Pipe
B751	General Requirements for Nickel and Nickel Alloy Welded Tube

Mechanical Property of Incoloy 825 Nickel Alloy

Form	Condition	0.2% Proof Stress MPa	Tensile Strength MPa	Elong %
Tube	Annealed	440	770	35
Tube	Cold drawn	880	1000	15
Bar	Annealed	325	690	45
Plate	Annealed	340	660	45
Sheet	Annealed	420	760	39

Key Properties & Corrosion Resistance

Incoloy 825 is designed to provide exceptional resistance to:

Reducing acids (Sulfuric and Phosphoric acid).
Oxidizing acids (Nitric acid, Chromic acid).
Chloride Stress Corrosion Cracking (SCC) – Superior to 300 series stainless steels.
Pitting and Crevice corrosion (due to Mo, Cu, and Ti content).
Sour gas environments (NACE MR0175 / ISO 15156 compliant for H₂S).

Application

Because of its high strength and corrosion resistance, the seamless pipe is used in:
Oil & Gas: Downhole tubing, sour gas service, surface flow lines.
Chemical Processing: Sulfuric acid plants, phosphoric acid evaporators, pickling tanks.
Pollution Control: Scrubber components in coal-fired power plants.
Marine: Offshore platforms (seawater handling).
Nuclear Fuel Reprocessing.
